100

101

Mon

0:00

Sequence Timer 2

1:00

(cont.)

2:00

3:00

4:00

5:00

6:00

Sequence Timer 2

Run at d1-03

7:00

8:00

9:00

10:00

11:00

12:00

13:00

14:00

15:00

16:00

17:00

18:00

19:00

20:00

21:00

22:00

23:00

Sequence Timer 1

Run at d1-01

SunSatFri

Thur

Wed

Tue

Figure 5.52 Sequence Timer Example 2

Sequence Timer Example 3

Set the parameters as shown in Table 5.25 to accomplish the timer sequencing in Figure 5.53.

Table 5.25 Sequence Timer Example 3 Parameter Settings

No. Name Setting Comment

S2-01 Sequence Timer 1 Start Time 05:00

S2-02 Sequence Timer 1 Stop Time 15:00

S2-03 Sequence Timer 1 Day Selection 2 Mon to Fri

S2-04 Sequence Timer 1 Selection 1 Run

S2-05 Sequence Timer 1 Reference Source 0 Operator (d1-01)

S2-06 Sequence Timer 2 Start Time 15:00

S2-07 Sequence Timer 2 Stop Time 22:00

S2-08 Sequence Timer 2 Day Selection 2 Mon to Fri

S2-09 Sequence Timer 2 Selection 2 Run PI Disable

S2-10 Sequence Timer 2 Reference Source 1 Operator (d1-02)

S2-11 Sequence Timer 3 Start Time 09:00

S2-12 Sequence Timer 3 Stop Time 24:00

S2-13 Sequence Timer 3 Day Selection 9 Sat

S2-14 Sequence Timer 3 Selection 1 Run

S2-15 Sequence Timer 3 Reference Source 2 Operator (d1-03)

S2-16 Sequence Timer 4 Start Time 0:00 n/a

S2-17 Sequence Timer 4 Stop Time 0:00 n/a

S2-18 Sequence Timer 4 Day Selection 0 Timer Disabled

S2-19 Sequence Timer 4 Selection 0 n/a

S2-20 Sequence Timer 4 Reference Source 0 n/a

5.12 S: Special Parameters

YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual

191

Programming
