Continue at Last Speed with Alarm

For this condition, Communication Fault Enable (BO 11) must be enabled and Cable Loss Speed (AO 22) should be set to a

value other than 0. An AL14 Serial Communications Alarm is shown.

Continue at Preset Speed with Alarm

In this mode, Cable Loss Timeout (AO 21) is set to the desired interval, Cable Loss Speed (AO 22) is set to the desired preset

speed and Z3–05 is set to “4”. If the time between messages exceeds the timeout interval, the drive speed command (AO 1)

is set to the Cable Loss Speed (AO 22) and the drive continues running at this new speed. Communication Fault Enable (BO

11) must be set to ‘On’.

Stop with Fault (FB14)

Communication Fault Enable (BO 11) must be set to ‘On’. In this mode, Cable Loss Timeout (AO 21) is set to the desired

interval and parameter F6-03 is set to a value of 0,1 or 2. If the time between messages exceeds the timeout interval, the drive

will declare an EF0 fault and the drive speed command (AO 1) will be set to 0. The stopping method is determined by the

setting of F6-03.

• F6–03 = 0 selects Ramp to Stop. The deceleration time or the slope of the ramp is determined by the setting of drive parameter

C1-02

• F6–03 = 1 selects Coast to Stop. The drive does not attempt to control the rate of deceleration.

• F6–03 = 2 selects Emergency or Fast Stop. The deceleration time is determined by the setting of drive parameter C1-09.

Bypass Fault Numbers

Table F.3 Fault Trace / History Register Contents

Fault Code Fault Name

0002H Undervoltage (Uv1)

0003H Control Power Supply Undervoltage (Uv2)

0004H Soft Charge Circuit Fault (Uv3)

0006H Ground Fault (GF)

0007H Overcurrent (oC)

0008H Overvoltage (ov)

0009H Heatsink Overheat (oH)

000AH Heatsink Overheat (oH1)

000BH Motor Overload (oL1)

000CH Drive Overload (oL2)

000DH Overtorque Detection 1 (oL3)

0010H Braking Resistor Overheat (rH)

0011H External Fault at Input Terminal S3 (EF3)

0012H External Fault at Input Terminal S4 (EF4)

0013H External Fault at Input Terminal S5 (EF5)

0014H External Fault at Input Terminal S6 (EF6)

0015H External Fault at Input Terminal S7 (EF7)

001BH Input Phase Loss (PF)

001CH Output Phase Loss (LF)

001DH Motor Overheat (PTC input) (oH3)

001EH Digital Operator Connection (oPr)

001FH EEPROM Write Error (Err)

0020H Motor Overheat (PTC input) (oH4)

0021H MEMOBUS/Modbus Communication Error (CE)

0022H Option Communication Error (bUS)

0027H Option External Fault (EF0)

0028H PI Feedback Loss (FbL)

0029H Undertorque Detection 1 (UL3)

002BH High Slip Braking Overload (oL7)

0030H Hardware Fault (including oFx)

0036H Output Current Imbalance (LF2)

Fault Code Fault Name

0037H Pullout Detection (Sto)

003BH Too Many Speed Search Restarts (SEr)

0041H PI Feedback Loss (FbH)

0042H External Fault 1, Input Terminal S1 (EF1)

0043H External Fault 2, Input Terminal S2 (EF2)

0046H Current Offset Fault (CoF)

0047H PLC Detection Error 1 (PE1)

0048H PLC Detection Error 2 (PE2)

004DH Output Voltage Detection Fault (voF)

0052H Node Setup Fault (nSE)

005AH Motor Underload Protection (UL6)

0083H A/D Conversion Error (CPF02)

0084H PWM Data Fault (CPF03)

0087H EEPROM Memory Data Error (CPF06)

0088H Terminal Board Connection Error (CPF07)

0089H EEPROM Serial Communication Fault (CPF08)

008CH RAM Fault (CPF11)

008DH Flash Memory Circuit Exception (CPF12)

008EH Watchdog Circuit Exception (CPF13)

008FH Control Circuit Fault (CPF14)

0091H Clock Fault (CPF16)

0092H Timing Fault (CPF17)

0093H Control Circuit Fault (CPF18)

0094H Control Circuit Fault (CPF19)

0095H Hardware Fault at Power Up (CPF20)

0096H Hardware Fault at Communication Start Up (CPF21)

0097H A/D Conversion Fault (CPF22)

0098H PWM Feedback Fault (CPF23)

0099H Drive Unit Signal Fault (CPF24)

009AH Terminal Board is Not Properly Connected. (CPF25)

009BH ASIC BB Circuit Error (CPF26)

F.4 Bypass Operations by N2

YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual

427

Metasys N2 Network

Protocol
