Fault Code Fault Name
0102H Option Not Properly Connected (oFA01)
0106H A/D Conversion Error (oFA05)
0107H Option Response Error (oFA06)
0111H Option RAM Fault (oFA10)
0112H Option Operation Mode Fault (SLMOD) (oFA11)
0113H Drive Receive CRC Error (oFA12)
0114H Drive Receive Frame Error (oFA13)
0115H Drive Receive Abort Error (oFA14)
0116H Option Receive CRC Error (oFA15)
0117H Option Receive Frame Error (oFA16)
0118H Option Receive Abort Error (oFA17)
0131H Comm. ID Error (oFA30)
0132H Model Code Error (oFA31)
0133H Sumcheck Error (oFA32)
0134H
Comm. Option Timeout Waiting for Response
(oFA33)
0135H MEMOBUS Timeout (oFA34)
0136H Drive Timeout Waiting for Response (oFA35)
0137H CI Check Error (oFA36)
0138H Drive Timeout Waiting for Response (oFA37)
0139H Control Command Selection Error (oFA38)
013AH Drive Timeout Waiting for Response (oFA39)
013BH Control Response Selection 1 Error (oFA40)
013CH Drive Timeout Waiting for Response (oFA41)
013DH Control Response Selection 2 Error (oFA42)
Fault Code Fault Name
013EH Control Response Selection Error (oFA43)
0401H Time Not Set (TIM)
0402H Operator Battery Low (bAT)
0403H Time Data Error (TdE)
0404H Time Interval Error (TiE)
0405H Overvoltage 2 (ov2)
0407H External Fan Fault (Fn1)
138CH NA
1393H Bypass Board Hardware Error
1396H Serial Communications Timeout
2711H
<1>
Safety Open
2712H
<1>
BAS InterLock Open
2713H
<1>
External Fault (EFB)
2715H
<1>
Motor Overload
2716H
<1>
Ext Motor1 Overload
2717H
<1>
Ext Motor2 Overload
2718H
<1>
PL Brownout
2719H
<1>
PL Blackout
271AH
<1>
No Bypass to Drive Communications
271CH
<1>
Option Board Communication Fault
217DH
<1>
Loss of Load
2720H
<1>
Input Phase Rotation
<1> Available in bypass controller software versions VST800298 and later. Displayed by P1 Apogee Point LAI 17.
Note: Drive fault codes are listed in the Apogee User Manual (TOEP YAICOM 09).
E.7 Fault Codes
YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual
417
E
Apogee FLN Network
Protocol
