Front Views
C
E
F
E
G
D
A
B
Z1B1D002
Z1B1D074
A
B
C
EE
F
G
D
A – Terminal TB3
B – Jumper S1
C – Jumper S5
D – Terminal TB4
E – Ground terminal
F – EMC filter switch SW2
G – EMC filter switch SW1
Figure 1.7 Front View of Z1000 Drives
1.5 Bypass Component Names
YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual
35
1
Receiving
