A – Cable hook
B – Cable tie hole
C – Cable anchor
Figure 3.38 Control Terminal Wiring (Model Z1B1B124)
A
B
A – Cable tie hole
B – Cable hook
Figure 3.39 Control Terminal Wiring (Models Z1B1D143 to D396 and B156 to B590)
3.5 Control Circuit Wiring
YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual
83
3
Electrical Installation
